Slot.it CH32D Ready to Run HRS2 Chassis (1.0mm. Be The First To Review This Product! Help other Slot Shop users shop smarter by writing reviews for products you. The Slot.it HRS2 chassis is a fully configurable, universal plastic chassis for slot cars. Assembled and ready to run in sidewinder configuration. Adjustable wheelbase: 64mm-90mm; Adjustable wheel width: 57mm-61mm; Height: 19mm; Chassis Features. Selectable front axle position; Flexible assembly system; Aluminum rear wheels 15.8x8.2mm.

Slot.it HRS2 complete and ready to run adjustable racing chassis to mount onto a wide range of slot car bodies.

Chassis Data

Adjustable wheelbase: 64mm-90mm
Adjustable wheel width: 60.6mm-64mm
Height: 19mm

Chassis Features

New anglewinder gear 28t (SIGA1628-PL)
New rear aluminum wheels 17.3x9.75mm (SIPA62-ALS)
Plastic front wheels 17.3x8.2mm
1167C1 rear tires
1045C1 front tires
Long-Can 21,500rpm Boxer/2 motor
Pickup guide (SICH66)
12t brass pinion
1mm offset anglewinder motor mount
Rear axle stopper
Adjustable front axle ride height
Body to chassis cups
Wheel inserts

HRS Chassis

The HRS chassis is a fully configurable, universal plastic chassis for slot cars. It comprises four main parts: main chassis, front chassis, motor mount, and body mounting means.

Adjustable Wheelbase

Slot it hrs2 chassis review and accessories

The front chassis can be positioned freely within a wheelbase between 64 and 90mm.

Selectable Front Axle Position

The front axle can be placed in one of two possible positions, one of which completely adjustable, making it easy to adjust the distance from the pickup.

Flexible Assembly System

The chassis and the body can be joined with either four mounting posts and cups (HRS1 style), two three-posts sidebars, or, on some cars, where possible, with the car’s own screw holes.

Product was successfully added to your shopping basket.

Details

Slot.it HRS2 complete and ready to run adjustable racing chassis to mount onto a wide range of slot car bodies.

Chassis Data

Adjustable wheelbase: 64mm-90mm
Adjustable wheel width: 60.6mm-64mm
Height: 19mm

Chassis Features

Anglewinder gear 28t (SIGA1628-PL)
Rear aluminium wheels 17.3x9.75mm (SIPA62-ALS)
Plastic front wheels 17.3x8.2mm
1167C1 rear tyres
1167C1 front tyres
Long-Can 21,500rpm Boxer/2 motor
Pickup guide (SICH66)
12t brass pinion
1mm offset anglewinder motor mount
Rear axle stopper
Adjustable front axle ride height
Body to chassis cups
Wheel inserts
Screws (SICH41b)

HRS Chassis
The HRS chassis is a fully configurable, universal plastic chassis for slot cars. It comprises four main parts: main chassis, front chassis, motor mount, and body mounting means.

Adjustable Wheelbase
The front chassis can be positioned freely within a wheelbase between 64 and 90mm.

Selectable Front Axle Position
The front axle can be placed in one of two possible positions, one of which completely adjustable, making it easy to adjust the distance from the pickup.

Flexible Assembly System
The chassis and the body can be joined with either four mounting posts and cups (HRS1 style), two three-posts sidebars, or, on some cars, where possible, with the car’s own screw holes.

Additional Information

Ref	SICH32d
Brand	Slot.it
Scale	1/32
